Dear u-boot mailing list,

Recently I am working on a graduation project at Prodrive Technologies including the development of firmware for a Marvell Ethernet switch chip: 98DX3235. For parallel hardware/software development, I got access to another Marvell Ethernet switch chip 98DX3336 placed in a Marvell RD-XC3-24G4XG-B switching unit. To prepare a u-boot bootloader I am using the following components

U-boot version: 2013.01 Marvell u-boot configurations: 2013.01-2016_T1.0.eng_drop_v6 Cross compiler: armv7-marvell-linux-gnueabi-softfp-4.6.4_64K_i686_20160226

I also have got a working u-boot binary files from Marvell. Because I need to make changes to the u-boot configuration I need to compile my own u-boot binary files. I was able to compile a UART binary file and load it through UART using TeraTerm. At the u-boot commandline I got stuck. No commands are recognized by u-boot. See my terminal feedback below:

------------------- START TERMINAL WINDOW-------------------

BootROM 1.41

__ __ _ _ | / | __ _ _ ____ _____| | | | |/| |/ _` | '__\ \ / / _ \ | | | | | | (_| | | \ V / __/ | | |_| |_|__,_|_| _/ ___|_|_| _ _ ____ _ | | | | | __ ) ___ ___ | |_ | | | |___| _ \ / _ \ / _ | __| | |_| |___| |_) | (_) | (_) | |_ ___/ |____/ ___/ ___/ __| ** LOADER **

U-Boot 2013.01 (May 03 2018 - 11:22:30) Marvell version: 2016_T1.0.eng_drop_v6

Board: RD-XC3-24G-4SFP SoC: Alleycat3 Rev A1 running 2 CPUs CPU: Marvell PJ4B (584) v7 (Rev 2) LE CPU 0 CPU @ 800 [MHz] L2 @ 200 [MHz] TClock @ 200 [MHz] DDR @ 400 [MHz] DDR 16Bit Width, FastPath Memory Access, DLB Enabled DDR ECC Disabled DRAM: 512 MiB NAND: 1024 MiB SF: Detected MX25L25735E with page size 64 KiB, total 32 MiB PCI-e 0: Detected No Link. FPU initialized to Run Fast Mode. USB2.0 0: Host Mode

Map: Code: 0x1fede000:0x1ff95a4c BSS: 0x1ffefbe8 Stack: 0x1f9cdef0 Heap: 0x1f9ce000:0x1fede000 U-Boot Environment: 0x00100000:0x00110000 (SPI)

Net: | port | Interface | PHY address | |--------|-----------|--------------| | egiga0 | SGMII | In-Band | | egiga1 | SGMII | In-Band | egiga0 [PRIME], egiga1 Hit any key to stop autoboot: 0 Marvell>> > Unknown command '>' - try 'help' Marvell>> ? Unknown command '?' - try 'help' Marvell>> help Unknown command 'help' - try 'help' Marvell>> fli Unknown command 'fli' - try 'help' Marvell>> conin Unknown command 'conin' - try 'help' Marvell>>

-------------------END TERMINAL WINDOW-------------------

As you can see U-boot is loaded, hardware configurations are done, the serial interface works fine and unfortunately no commands are recognized by the u-boot. This got me thinking. My first thought was that the terminal in some way adds invisible characters to the commands. I tested this by printing all command characters separately before the Unknown command print function in u-boot. I saw that there were no other segments added to the command. I also tried using putty without any results. The binary file obtained by Marvell works fine but mine does not.

I also tried to compile and execute using 7 other cross compilers without any results.

The original Marvell UART binary file differs 24 bytes from my own compiled UART binary file. Apart from the Unknown command lines in the previously shown terminal window, both UART binary files print exactly the same information.

The only thing I can think of now is that my configuration in include/configs/<configurationfile.h>. is not well configured. A Part of the configuration file is shown below. Does someone know what is going wrong here? Do I have to change/add configurations or do I have to search somewhere else.

----------/include/configs/configfile---------

160 /*************************************/ 161 /* High Level Configuration Options */ 162 /* (easy to change) */ 163 /*************************************/ 164 #define CONFIG_MARVELL 165 #define CONFIG_SYS_64BIT_VSPRINTF 166 #define CONFIG_SYS_64BIT_STRTOUL 167 #define CONFIG_API 168 169 /* commands */ 170 #define CONFIG_BOOTP_DEFAULT (CONFIG_BOOTP_MASK | CONFIG_BOOTP_BOOTFILESIZE) 171 #define CONFIG_CMD_DHCP 172 #define CONFIG_CMD_ELF 173 #define CONFIG_CMD_I2C 174 #define CONFIG_CMD_EEPROM 175 #define CONFIG_CMD_NET 176 #define CONFIG_CMD_PING 177 //#define CONFIG_CMD_DATE 178 #define CONFIG_CMD_LOADS 179 #define CONFIG_CMD_BSP 180 #define CONFIG_CMD_MEMORY 181 #define CONFIG_CMD_BOOTD 182 #define CONFIG_CMD_BOOTZ 183 #define CONFIG_CMD_CONSOLE 184 #define CONFIG_CMD_RUN 185 #define CONFIG_CMD_MISC 186 #define CONFIG_CMD_IDE 187 #define CONFIG_CMD_SCSI 188 #define CONFIG_CMD_SAR 189 #define CONFIG_CMD_STAGE_BOOT 190 #define CONFIG_CMD_RCVR 191 #define CONFIG_CMD_BOOT_MENU 192 193 #define CONFIG_ENV_MIN_ENTRIES 128 194 195 #if (defined(MV_INCLUDE_PEX) || defined(MV_INCLUDE_PCI)) 196 #define CONFIG_PCI 197 #define CONFIG_CMD_PCI 198 #endif 199 200 /* Pre eXecution Environment (PXE) support*/ 201 #define CONFIG_CMD_PXE 202 #define CONFIG_BOOTP_PXE 203 #define CONFIG_MENU 204 #define CONFIG_BOOTP_PXE_CLIENTARCH 0x100 205 #define CONFIG_BOOTP_VCI_STRING "U-boot.armv7.armada_xp"

Kind regards,
