Hi Jagan,

Have you check the memory area, does it maybe overlap with other area? eg. heap, stack, malloc area and etc.

Thanks,

- Kever

On 2024/1/17 18:36, Jagan Teki wrote:

Hi All,

Artifact occurred only during boot but loading via the bmp command on the u-boot console seems fine.

I have observed the contents of bmp hex codes have changed during the function switch after memory to ddr address. (The same cannot happen on downstream u-boot)

diff --git a/common/splash.c b/common/splash.c index 6820db683b..f97edf8732 100644 --- a/common/splash.c +++ b/common/splash.c @@ -175,6 +175,11 @@ int splash_display(void)

     splash_get_pos(&x, &y);

•   if (memcmp((void *)addr, bmp_logo_bitmap, len2) == 0)


•           printf("%s: SAME\n", __func__);


•   else


•           printf("%s: NOTSAME\n", __func__);


•    if (CONFIG_IS_ENABLED(BMP))
             ret = bmp_display(addr, x, y);
     else


diff --git a/drivers/video/bmp.c b/drivers/video/bmp.c index bab6fa7265..dc2928ccdb 100644 --- a/drivers/video/bmp.c +++ b/drivers/video/bmp.c @@ -111,10 +111,15 @@ int bmp_display(ulong addr, int x, int y) { struct udevice *dev; int ret;

•   struct bmp_image *bmp = map_sysmem(addr, 0);
     void *bmp_alloc_addr = NULL;
     unsigned long len;



•   if (memcmp((void *)addr, bmp_logo_bitmap, len2) == 0)


•           printf("%s: SAME\n", __func__);


•   else


•           printf("%s: NOTSAME\n", __func__);


•   struct bmp_image *bmp = map_sysmem(addr, 0);
     if (!((bmp->header.signature[0] == 'B') &&
           (bmp->header.signature[1] == 'M')))
             bmp = gunzip_bmp(addr, &len, &bmp_alloc_addr);



So, the contents in splash_display show SAME and the contents in bmp_display show NOTSAME.

This issue is reproducing on specifics like

• 24-bit BMP (attached).

rockchip.bmp: PC bitmap, Windows 98/2000 and newer format, 480 x 270 x 24

• Rockchip 64-bit SoC (32-bit, RK3288 has no issue).
• Allwinner 64-bit SoC seems no issues.
• Downstream u-boot rockchip has no issues. (with mainline vide

drivers not with drm drivers)

• Issue observed in boot but loading via bmp command on u-boot console

seems no issue.

I did check the clock, cache, and memory but none of them showed any clue. I did port clock, mach-rockchip code to rockchip u-boot but none of the cases resulted in the same.

Any input on this is appreciated.

Thanks, Jagan.
